1.73 Inch Round AMOLED Display Module 466x466 Resolution QSPI Interface Driver IC CO5300 Color Screen LCD Module for Smart Watch
1.73 Inch Round AMOLED Display Module 466x466 Resolution QSPI Interface Driver IC CO5300 Color Screen LCD Module for Smart Watch
Couldn't load pickup availability
SPECIFICATIONS
Brand Name: NONE
Display Mode: 10000:1
High-concerned chemical: none
Model Number: CO5300
Origin: Mainland China
Resolution: 480x480
Type: OLED
Product Introduction:
Engineered for high-performance applications, this 1.73-inch full-circle AMOLED delivers exceptional image quality with a native resolution of 466 × 466 pixels. The display offers a crisp pixel density of 326 PPI with a pixel pitch of 78 × 78 μm, ensuring sharp rendering of graphics and text within the active circular area (Φ43.76 mm).
The module incorporates a CO5300 display driver and integrates the CST820 touch controller, supporting responsive touch functionality. Communication is handled via a high-speed QSPI interface, optimized for low-latency data transfer.
Housed in a compact mechanical package (48.50 mm × 48.50 mm × 2.21 mm), this display is designed for space-constrained designs such as wearable technology and portable medical devices. It maintains stable operation across an industrial temperature range of -10 °C to +60 °C, with storage conditions rated from -20 °C to +70 °C.
Features:
1.73-inch True-Circle AMOLED Active Matrix
466 × 466 Full Color Resolution
CO5300 Display Driver + CST820 Touch Controller
High-Speed QSPI Interface
Ultra-Compact Form Factor
Industrial Operating Temperature Range
Pin definition
Schematic Showcase
